Caja Alphacool ES Rack 1U. Diseñada para RL.

The Alphacool ES 1U ServerRack has been specifically optimized to accommodate water cooling assemblies that can dissipate up to 490W of waste heat in this case. For this purpose, the housing not only offers a mounting frame for a maximum of one 7x40 mm copper radiator from the Alphacool NexXxoS series. The optionally available 40mm Alphacool ES fans with PWM control ensure optimal cooling performance.

The 1U server rack offers mounting options for two 5.25" drives on the left and right side of the front. Each 5.25" bay offers the option of mounting two 3.5" drives. Pre-included a support frame to mount up to four 2.5" drives. -mounted in the center front. This support frame can be mounted in five other cabinet positions.

All common screw connection options in the classic ATX format are available for mounting an SSI-EBB motherboard. This includes all mounting holes for Mini-ITX to EE-ATX. A graphics card in PCIe or low profile 0.8" format can also be installed using a riser cable. A corresponding panel for 0.8" cards is pre-mounted in the case.

With a suitable water cooling system, up to 490 W of waste heat can be dissipated. Alphacool offers special water cooling kits for this purpose, which can be configured individually and are delivered to the customer pre-filled. The mounting frame for the radiator and fans can be moved within the case to fit any configuration.

Main features...

* 1U Rack Box designed for RL.
* Compatible with Mini-ITX, Micro-ATX, ATX, E-ATX, EE-ATX, SSI-EEB boards.
* Supports up to 7 40mm fans.
* Internal bays: 4x 2.5", 2x 3.5" (in 2x 5.25" space).
* 1 PCI Slot.
