Panel Pc táctil 23.8" IP65 Fanless Bay Trayl-D J1900 2.0Ghz

Pn.

IP65 protection system with NEMA4 certification.
Fanless design (no moving parts that can generate failure).
Easy to clean flat surface with “edge to edge” design.
Great resistance to vibrations.
Broad connectivity.
Easy, universal mounting positions (wall, VESA and panel).
Continuity and long-term availability.

23.8 "touch panel PC panel specially designed for industrial environments thanks to its IP65 protection level. It provides a high degree of resistance and speed.

Specially designed for very low consumption and high heat dissipation capacity.

Highlights...

* Touch panel 23.8 ”IP65 / NEMA4 (certified protection against dust and water).
* Brightness 250 nits TFT LCD with LED backlight.
* 10-point capacitive touch protection screen, Anti-reflective.
* Low consumption.
* Integrated industrial power supply 9-28V DC, with EOS and OVP design (surge protection system).

Front	IP65, NEMA 4
Display type	23.8″ with LED backlight
Brightness (cd/m²)	250 nits
Color display	16.7M
Resolution	1920 x1080 @ 60Hz
Viewing angle (H/V)	160°/160°
Pixel size	0.2745 x 0.2745 mm
Format	16:09:00
Contrast	10/02/1900 16:01:00
Response time	25 ms
Touch screen
Type	Capacitive
Active range	528.04 x 297.46mm ±0.3mm
Transparency	85 ±5%
Surface hardness	≧6H (ASTM D3363, pressure 1N/45°)
Operating force	≦ 10g
Temp. operating	– 15 ~+ 65°C
Case
Material	Aluminum
Color	Silver/White
System
CPU	Intel® Bay Trail-D J1900 2.0GHz/QC
RAM	4G 1333MHz DDR3L SAMSUNG DRAM
BIOS	64MB SPI Flash ROM
Storage	1* 2.5” SATA bay 1* M.2 connector (2242/2260/2280)
Watchdog Timer	256 levels, 0~255 sec.
Supported operating systems	Windows 7 / 8.1 / 10 / Linux (Option)
I/0 Ports
USB 3.0	2
USB 2.0	4
USB 2.1	4
USB 2.2	4
USB 2.3	4
USB 2.4	4
USB 2.5	4
USB 2.6	4
USB 2.7	4
Expansion slots
PCI-E	1* PCI-E mini card for WIFI or 3G/4G
Power
Power input	Supports 9-28V DC Power in with over current protection fuse Provides 100~240V AC-DC 12V, 60W power adapter
Energy consumption	42.5W
Environmental conditions
Temp. operating	0 ~ 60° C (con W.T. DRAM/HDD con flujo de aire)
Hits	15G，11ms duration
Vibration	5~500Hz/1 Grms
Certifications and regulations
Certifications	CE, FCC, IP65(Front)
Regulations
Dimensions and weight
Dimensions	579.04x 360.46 x 76.00mm
Weight
