Netstor NA255A-G4. 4 puertos de ultra altavelocidad PCI 4.0x16

The Netstor NA255A-G4 GPU Chassis implements the latest ultra-high-speed PCIe 4.0 technology and 16-lane PCIe Gen4 host interface with a throughput of 16 Gbps per lane that delivers ultra-fast data transfer speeds of up to 256 Gbps between the host server/computer and expansion cabinet. dedicated for high-performance GPU-accelerated applications.

The GPU chassis is built to have four PCIe 4.0 ×16 (×16 electrically) slots on the NA255A-G4 backplane, which supports up to four triple/double-width PCIe Gen4 GPU cards, or third-party single-width PCIe cards. In addition, the enclosure can accommodate all combinations of PCIe 4.0 × 16, × 8, × 4 and × 1 GPU/PCIe cards for every application with backwards compatibility for Gen3 cards to work with server/workstation in various fields such as HPC, telecom, data centers and many more.

Newer high-end or enthusiast GPU cards typically require high-power wattage to run; In light of the high power requirement factors, Netstor has carefully planned a dedicated, high-wattage, highly-efficient power supply unit within the GPU chassis to allow up to four high-performance graphics cards to process and render at the same time. same time with maximum reliability and stability.

The Netstor NA255A-G4 GPU chassis has been carefully crafted to provide additional 6+2-pin PCIe power cables to meet the additional power requirements of each GPU card; therefore, the Netstor drive is fully compatible with any graphics card that comes with any combination of 6-pin or 8-pin PCIe power connectors.

In view of the high-performance GPU card with the length up to about 32cm, due to the heavy weight of the card, the wider width and the longer length, a special graphics card bracket has been designed to support each PCIe slot. ×16 inside the NA255A-G4 chassis in favor of holding the heavyweight GPU card firmly and reliably in order to run multiple high-end graphics cards inside the unit continuously.

The NA255A-G4 is equipped with two large 12 × 12 cm front cooling fan modules, each supporting a maximum flow of 106 CFM, providing the best airflow ventilation to the chassis for excellent dissipation. from heat while ensuring that the GPU cards inside the chassis can work continuously for a long time without any high. temporary concern. In addition, the fan speed of each cooling fan can be manually adjusted according to the situation of the GPU application inside the Netstor unit.

Main features...

* Technology: PCI Express 4.0.
* Host interface: Up to 256 Gb/s PCIe 4.0 x16 external.
* number of cards admitted: 4.
* Material: Solid metal frame with aluminum casing.
* Dimensions: 450 x 175.8 x 374 mm.
