Lanberg Armario Rack 19" 42U 800x1000 FF01-8042-12B

Pn. FF01-8042-12BEan. 5901969415001
Lanberg
  • Height 42U
  • Inner width of rail between rack rails: 450mm,
  • The width of the space between the openings of the rack rails: 465 mm,
  • The external width between the rack rails: 500 mm,
  • Load capacity: Up to 800KG,
  • Protection class: IP20,
  • Ventilation panel: 4 230V fans in the upper case included,
  • Door type : Front - Tempered glass, Back - Steel
  • Standards Compliance: ANSI/EIA RS-310D, IEC297-2, DIN41494; PART1 & PART7, ETSI,
  • Material: high quality rolled steel, powder coated,
  • Door thickness: 5.0mm,
  • Sheet thickness: vertical mounting rails - 2.00 mm; mounting profile - 2.00 mm; rest - 1.50mm - 1.20mm,
  • Cable Openings: Top, Bottom (adjustable)

The Lanberg FF01-8042-12B single section floor standing cabinet is a solution for network construction, cabling and equipment mounting, size 19”, with a maximum total load capacity of up to 800 kg. It can be used in data centers that require a large amount of device cabinet space. The cabinet will successfully fulfill its role in large and complex networks and server rooms, whether in small, medium and large companies or corporations.

It will also work well in low voltage installations such as cable TV networks, alarm systems, fire protection systems, access control systems, as well as CCTV and IP monitoring systems. The structure is made of high quality rolled steel, it is characterized by excellent design and quality of workmanship. The cabinet allows for full depth adjustment of the vertical mounting rails.

It is equipped with a lockable tempered glass front door, which can be mounted on the right or left side. It has removable side panels (locks included) and a lockable solid steel rear door. There is the possibility of introducing the wiring through the closed upper and lower panel (with plugs included).

Main features...

* Height 42U.
* The width of the space between the openings of the rack rails: 465 mm.
* 74mm PWM fan.
* Protection class: IP20,.
* Load capacity: Up to 800 KG,.
