Gigabyte XV24-SU0 rev. AAJ1 (Hasta 4 GPUs)

The Gigabyte XV24-SU0-AAJ1 is a high-performance server designed for AI, deep learning, and next-generation data center environments. Its compatibility with Intel® Xeon® 6 Series processors (6700 and 6500) with up to 136 PCIe lanes per CPU delivers exceptional performance and complete flexibility for compute-intensive workloads.

This 2U server supports up to 16 DDR5 RDIMM or MRDIMM slots, achieving speeds of up to 8000 MT/s (MRDIMM 1DPC) and eight-channel configurations per processor, ensuring extreme memory bandwidth. Its advanced architecture makes it an ideal solution for data analysis, scientific simulation, and AI model training.

The XV24-SU0 is optimized for high-density GPU environments, supporting either 4 × NVIDIA H200 NVL PCIe or 4 × RTX PRO 6000 Blackwell Server Edition graphics cards, integrated via 2-way NVLink bridges for maximum connectivity. It features up to seven PCIe Gen5 x16 slots, two front-facing hot-swap Gen5 NVMe bays, and two internal M.2 PCIe Gen5 x4 slots, ensuring ultra-fast storage and expansion.

Its remote management system, based on the ASPEED AST2600 controller, includes an HTML5 KVM console, dedicated management LAN, and dual 10GbE networking (Intel X550-AT2). The redundant 2000W 80 PLUS Titanium 3+1 power supply ensures maximum efficiency and continuous availability, while its 2U chassis is designed to maintain optimal cooling even with high-power GPUs.

Key Features...

* Compatible with Intel® Xeon® 6 Series (6700/6500) processors up to 350W TDP.
* 16 DDR5 RDIMM/MRDIMM slots up to 8000 MT/s (MRDIMM 1DPC).
* Support for 4 × NVIDIA H200 NVL PCIe or 4 × RTX PRO 6000 Blackwell Server Edition.
* 7 PCIe Gen5 x16 slots for GPU, NIC, and DPU.
* 2 hot-swap 2.5" Gen5 NVMe bays + 2 M.2 PCIe slots Gen5 x4.
* 2 x 10 GbE LAN ports (Intel X550-AT2) + 1 x 1 GbE management LAN.
* ASPEED AST2600 controller with integrated HTML5 KVM and Mini-DP.
* Redundant 2000W 80 PLUS Titanium 3+1 power supply.
