Trendnet TI-PG50F. Switch PoE Gestionado 5 Puertos Gigabit.

Trendnet TI-PG50F. Switch PoE Gestionado 5 Puertos Gigabit.

Trendnet
  • 4 x Gigabit PoE+ ports.
  • 1 x Gigabit port.
  • 120W PoE power budget.
  • 10Gbps switching capacity.
  • Supports jumbo frames up to 9KB.
  • Hardened IP30 rated metal housing.
  • Includes wall mounting and DIN-Rail brackets.
  • Operating temperature range of -40° – 75° C (-40° – 167° F).
  • Redundant power inputs with overload current protection.
  • Alarm relay triggered by power failure.
  • Power supply sold separately (models: TI-S12048, TI-S24048, and 48VDC3000).

P/N: TI-PG50F - EAN/UPC: 0710931161564

160,38 € Without VAT
194,06 € With VAT
Only 1 unit left
Approximate delivery between 23 septiembre and 24 septiembre
2 years
of guarantee
sending
shipping
100%
Secure pay

TRENDnet's Industrial Gigabit PoE+ Wall-Mounted Front Access Switch Series are well suited for IP surveillance, IoT, and automation networks for homes and businesses. These hardened industrial gigabit flat switches provide front access to ports and power interfaces for easier installation. The flat and compact size make them ideal for cabinet installations where space is limited. Each hardened industrial front access switch features gigabit PoE+ ports for connecting devices such as wireless access points, IP cameras, and IoT appliances. These hardened front access switches come equipped with an IP30 rated metal enclosure, designed to withstand a high degree of vibration and shock, while operating within a wide temperature range of -40° – 75° C (-40° – 167° F) for industrial environments.

The wall mountable flat switch provides front access to ports and power interfaces for easier installation. It's flat and compact size make it ideal for cabinet installations where space is limited.

A 120W PoE power budget supplies PoE power from the hardened industrial front access switch to up to five Power over Ethernet devices.

Equipped with an IP30 rated metal enclosure, this front access switch is designed to withstand a high degree of vibration and shock, while operating within a wide temperature range of -40° – 75° C (-40° – 167° F) for industrial environments.

Hardened industrial housing offers a wide operating temperature range of -40° – 75° C (-40° – 167° F), allowing for installations in extreme hot and cold environments

Hardened design rated for shock (EN 60068-2-27), freefall (EN 60068-2-32), and vibration (EN 60068-2-6) for industrial settings

Highlights...

* 4 x Gigabit PoE+ ports.
* 1 x Gigabit port.
* 10Gbps switching capacity.
* Hardened IP30 rated metal housing.
* Includes wall mounting and DIN-Rail brackets.
* Operating temperature range of -40° – 75° C (-40° – 167° F).
* Redundant power inputs with overload current protection.
* Power supply sold separately (models: TI-S12048, TI-S24048, and 48VDC3000).

Standards
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3ab
  • IEEE 802.3x
  • IEEE 802.3af
  • IEEE 802.3at
Device Interface
  • 4 x Gigabit PoE+ ports
  • 1 x Gigabit port
  • 6-pin removable terminal block
  • LED indicators
  • DIN-Rail mount
  • Wall mount
  • Grounding point
Data Transfer Rate
  • Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
  • Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
  • Gigabit: 2000 Mbps (full duplex)
Performance
  • Data RAM Buffer: 1024KB
  • Switching Fabric: 10Gbps
  • MAC Address Table: 2K entries
  • Jumbo Frame: 9KB
  • Forwarding rate: 7.44Mpps (64-byte packet size)
Special Features
  • Hardened components rated for extreme temperatures
  • Redundant power inputs
  • Auto-Negotiation
  • Auto store and forward architecture
  • Automatic address learning and address aging
  • ESD 8KV support
DC Power
  • Input: 48 - 56 V DC
  • Compatible power supply: TI-S24048 (sold separately)
  • Max. consumption: 5W (no PoE)
Optional Power Adapter (48VDC3000 sold separately)
  • Input: 100 - 240 V AC, 50/60 Hz, 2 A
  • Output: 48V DC, 3.34A 160W max.
PoE
  • PoE budget: 120W
Terminal Block
  • Redundant power inputs, alarm relay contact, 6 pin
  • Wire range: 0.34mm^2 to 2.5mm^2
  • Solid wire (AWG): 12-24/14-22
  • Stranded wire (AWG): 12-24/14-22
  • Torque: 5 lb. – In / 0.5Nm / 0.56 Nm
  • Wire strip length: 7-8mm
Alarm Relay Contact
  • Relay outputs with current carrying capacity of 1A, 24V DC
  • Open circuit mode when two power sources are connected
  • Short circuit mode when only one power source is connected
MTBF
  • 454,556 hours
Housing
  • IP30 metal case
  • DIN-rail mount
  • Wall mount
  • Grounding point
Operating Temperature
  • - 40° - 75° C (-40° - 167° F)
Operating Humidity
  • Max. 95 % non-condensing
Dimensions
  • 118 x 118 x 23.2mm (4.6 x 4.6 x 0.9 in.)
Weight
  • 425g (14.9 oz.)
Certifications
  • CE
  • FCC
  • UL
  • Shock (IEC 60068-2-27)
  • Freefall (IEC 60068-2-32)
  • Vibration (IEC 60068-2-6)
