Tooq XGE TQXGE II 700SAP 80Plus Bronze

Tooq XGE TQXGE II 700SAP 80Plus Bronze

Tooq
  • ATX 700W power supply.
  • 80+ Bronze certification.
  • 140mm fan with blue led.
  • Noise: <17dBA.
  • 2 12V rails.

P/N: TQXGEII-700SAP - EAN/UPC: 8433281007598

48,88 € Without VAT
59,14 € With VAT
In stock
Delivery 24/48h working
2 years
of guarantee
sending
shipping
100%
Secure pay

TOOQ's XGE II gaming series is designed for very enthusiastic gamers and demanding setups.

This series of high-performance power supplies is 80 PLUS BRONZE certified, guaranteeing more than 82% efficiency. The powerful + 12V output ensures powering of next-generation multi-core GPUs and microprocessors.

This source incorporates a fan with a blue LED light that can be turned off by means of a red switch that we can find together with the rest of the connections, leaving it well differentiated from the power switch, to adapt to the needs of each user. The fan has bearings made with double ball bearings, which has an extremely long service life (more than 20 years of service life with use of 10 hours a day).

We know that demanding gamers use tall towers, therefore this font incorporates extra long, meshed cables for players to calmly mount their gear without surprise.

In conclusion, it is the perfect powerful "heart" to push your super team setup.

Highlights...

* ATX 700W power supply.
* 80+ Bronze certification.
* Silent 140mm fan with blue Led.
* Low noise level: <17 dBA.
* Full protection: OCP, OVP, UVP, SCP, OPP, OTP.
* Connectors: 1 20/24 connector, 2 6 + 2-pin PCIe connectors, 1 P4 + P4 connector, 3 4-pin connectors, 1 FDD power connector and 6 SATA power connectors.

Datos técnicos
Potencia 700W
Modelo TQXGEII-700SAP
Voltaje/Frecuencia 110-230VAC / 10-5A / 50-60Hz
Normativa ATX 12V 2.31
Ventiladores 140mm con Led azul
Nivel Ruido, dB(A) <17dBA
12V Raíles 2
Protecciones OCP, OVP, UVP, SCP, OPP, OTP
Certificaciones 80+ Bronze/ Active PFC
Durabilidad > 100.000 horas

Cableado
A Placa Base 1 x ATX 20+4-Pines / 1 x P4+P4 conector
A Dispositivos 3  x 4 Pines Molex (HDD) / 6 x SATA (5 Pines) / 1 x 4-Pines Floppy
A VGA 2 x 6+2 Pin PCI-Express
Extras


Datos salida/entrada corriente

AC Input

110-230VAC / 10-5A / 50-60Hz

DC Output

3,3V

5V

12V1

12V2





-12V

5VSB

max. current

20A

20A

25A

25A





0.5A

2A



max. Combined power

110W

574W

6W

10W

700W


Dimensiones
Ancho 150mm
Alto 86mm
Fondo 160mm
Peso 2.35 Kg
  Ver.1.1.
