SilverStone SST-TX500-G TFX (80 Plus Gold)
- Accepts standard TFX form factor
- Continuous output power of 500W at an operating temperature of 50ºC, suitable for continuous use
- High efficiency with 80 PLUS Gold certification
- Silent 80mm fan with a minimum of 18dBA
- Accepts single 6 + 2-pin PCI-E connector
- Multiple protection circuitry
of guarantee
Insured
Secure pay
Formate | |
Power | |
Certification |
Designed to 80 PLUS Gold efficiency level to reduce wasted heat and save electricity
Included 80mm fan with excellent airflow and low noise, perfect for use in the office or at home
Powerful + 12V single rail design, perfect for future high-end upgrade components or overclocking
Highlights...
* Accepts standard TFX form factor.
* Continuous output power of 500W at an operating temperature of 50ºC.
* High efficiency with 80 PLUS Gold certification.
* Accepts single PCI-E 6 + 2 pin connector.
* Multiple protection circuitry.
úmero de producto |
SST-TX500-G |
||||||||||||||||||||||||||||||||||||||||||
Max. salida DC |
500W |
||||||||||||||||||||||||||||||||||||||||||
Densidad de potencia |
517W por litro |
||||||||||||||||||||||||||||||||||||||||||
Rango de carga |
|||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||
Modelo (seguridad) |
SST-TX500-G |
||||||||||||||||||||||||||||||||||||||||||
Color |
Negro (color sin plomo) |
||||||||||||||||||||||||||||||||||||||||||
Combinado +3.3V & +5V |
100W |
||||||||||||||||||||||||||||||||||||||||||
Combinado+12V |
499,2W |
||||||||||||||||||||||||||||||||||||||||||
Voltaje de entrada |
90 ~ 264 Vrms |
||||||||||||||||||||||||||||||||||||||||||
Rango de voltaje de entrada |
47Hz ~ 63Hz |
||||||||||||||||||||||||||||||||||||||||||
PFC |
Active PFC (PF>0.9 en plena carga) |
||||||||||||||||||||||||||||||||||||||||||
Eficiencia |
87% ~ 90% (al 20% ~ 100% de carga) |
||||||||||||||||||||||||||||||||||||||||||
MTFB |
100,000 horas |
||||||||||||||||||||||||||||||||||||||||||
Temperatura operativa |
0 ~ 50°C |
||||||||||||||||||||||||||||||||||||||||||
Protecciones |
Protección por exceso de corriente |
||||||||||||||||||||||||||||||||||||||||||
Conectores |
1 x conector placa madre 24 / 20 pin (350mm) |
||||||||||||||||||||||||||||||||||||||||||
Sistema de refrigeración |
Ventilador silencioso 80mm HYB |
||||||||||||||||||||||||||||||||||||||||||
Formato | TFX | ||||||||||||||||||||||||||||||||||||||||||
Nivel sonoro |
18 dBA min. |
||||||||||||||||||||||||||||||||||||||||||
Medidas |
85mm (L) x 65mm (A) x 175mm (G) |
||||||||||||||||||||||||||||||||||||||||||
Peso |
1,38 kg |
||||||||||||||||||||||||||||||||||||||||||
Certification |
80 PLUS Gold |
||||||||||||||||||||||||||||||||||||||||||
Varias |
Compatible with ATX12V v2.4 |
