SilverStone SST-TX300 TFX 300W (80 Plus Bronze)
- Accepts standard TFX form factor
- 300W continuous power output at 40ºC operating temperature, suitable for continuous use
- High efficiency with 80 PLUS Bronze certification
- Silent 80mm fan with a minimum of 18dBA
- Accepts single 6-pin PCI-E connector
- Active PFC
of guarantee
Insured
Secure pay
Designed with an 80 PLUS Bronze efficiency level to reduce waste heat and save electricity.
Included 80mm fan with excellent airflow and low noise, perfect for use in the office or at home.
Highlights...
* Accepts standard TFX form factor.
* Continuous output power of 300W at an operating temperature of 40ºC, suitable for continuous use.
* High efficiency with 80 PLUS Bronze certification.
* Silent 80mm fan with a minimum of 18dBA.
* Accepts single 6-pin PCI-E connector.
Modelo No. |
SST-TX300 |
|||||||||||||||||||||||||||||||||||||||||||||||||
Max. salida DC |
300W |
|||||||||||||||||||||||||||||||||||||||||||||||||
Densidad de potencia |
310W por litro |
|||||||||||||||||||||||||||||||||||||||||||||||||
Rango de carga |
||||||||||||||||||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||||||||||||||||
Color |
Negro (pintura sin plomo) |
|||||||||||||||||||||||||||||||||||||||||||||||||
Combinado +3.3V & +5V |
95W |
|||||||||||||||||||||||||||||||||||||||||||||||||
Combinado+12V |
276W |
|||||||||||||||||||||||||||||||||||||||||||||||||
Voltaje de entrada |
90 ~ 264 Vrms |
|||||||||||||||||||||||||||||||||||||||||||||||||
Rango de voltaje de entrada |
47Hz ~ 63Hz |
|||||||||||||||||||||||||||||||||||||||||||||||||
PFC |
Active PFC (PF>0,9 en plena carga) |
|||||||||||||||||||||||||||||||||||||||||||||||||
Eficiencia |
82% ~ 85% al 20% ~ 100% de carga |
|||||||||||||||||||||||||||||||||||||||||||||||||
MTFB |
100,000 horas |
|||||||||||||||||||||||||||||||||||||||||||||||||
Temperatura operativa |
0°C ~ 40°C |
|||||||||||||||||||||||||||||||||||||||||||||||||
Protecciones |
Protección por exceso de potencia |
|||||||||||||||||||||||||||||||||||||||||||||||||
Conectores |
1 x conector placa madre 24 / 20 pin (350mm) |
|||||||||||||||||||||||||||||||||||||||||||||||||
Sistema de refrigeración |
Ventilador silencioso de 80mm |
|||||||||||||||||||||||||||||||||||||||||||||||||
Formato | TFX | |||||||||||||||||||||||||||||||||||||||||||||||||
Nivel sonoro |
Mínimo de 18dBA |
|||||||||||||||||||||||||||||||||||||||||||||||||
Medidas |
85 mm (L) x 65 mm (A) x 175 mm (G) |
|||||||||||||||||||||||||||||||||||||||||||||||||
Peso |
1 kgs |
|||||||||||||||||||||||||||||||||||||||||||||||||
Certification |
80 PLUS Bronze |
|||||||||||||||||||||||||||||||||||||||||||||||||
Varias |
Compatible with ATX12V v2.4 |
