SilverStone SST-ST65F-GS 650W (80 Plus Gold)
- Compact design with 140mm depth for easy integration.
- 80 PLUS Gold certified.
- 100% modular cables.
- 24/7 continuous output power with 40 ° C operating temperature.
- Class-leading single rail + 12V.
- Strict ± 3% voltage regulation and low ripple and noise.
- Silent 120mm fan with a minimum of 18 dBA.
- Dual EPS 8pin with support for multiple PCI-E 8 / 6pin connectors (V1.1).
of guarantee
Insured
Secure pay
Designed for 80 PLUS Gold efficiency level to reduce heat waste and save electricity. The built-in 120mm fan has excellent airflow and low noise, perfect for quiet use at home or office.
3% regulation and low ripple and noise performance for high stability. Strider Gold S PSUs are the first power supply models in the world to include 24-pin ribbon cables. This cable offers much greater flexibility for tighter folding and superior cable management.
The 140mm depth sets a new standard for high-power PSUs with modular cables. 100% modular cable design for easy removal in a tied and routed cable case.
Powerful + 12V single rail design, perfect for future high-end component upgrades or overclocking.
Highlights...
* Compact design with 140mm depth for easy integration.
* 80 PLUS Gold certification.
* 100% modular cables.
* 24/7 continuous output power with 40 ° C operating temperature.
* Class-leading single + 12V rail.
* Strict ± 3% voltage regulation and low ripple and noise.
* Silent 120mm fan with a minimum of 18 dBA.
Datos Generales | |||||||||||||||||||||||||||||||||||||||
Rango de carga |
|||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||
Color |
Negro (pintura sin plomo)
|
||||||||||||||||||||||||||||||||||||||
Combinado + 3.3V y + 5V |
100W
|
||||||||||||||||||||||||||||||||||||||
Combinado + 12V |
648W
|
||||||||||||||||||||||||||||||||||||||
Voltaje de entrada |
90V ~ 264V
|
||||||||||||||||||||||||||||||||||||||
Rango de frecuencia de entrada |
47Hz ~ 63Hz
|
||||||||||||||||||||||||||||||||||||||
PFC |
PFC activo. (PF> 0.9 a plena carga)
|
||||||||||||||||||||||||||||||||||||||
Eficiencia |
87% ~ 90% a 20% ~ 100% de carga
|
||||||||||||||||||||||||||||||||||||||
MTBF |
100,000 horas
|
||||||||||||||||||||||||||||||||||||||
Temperatura de funcionamiento |
0 ° C ~ 40 ° C
|
||||||||||||||||||||||||||||||||||||||
Proteccion |
Protección
contra sobretensión Protección contra sobrecorriente Protección contra sobretensión Protección contra sobretemperatura Protección contra subtensión Protección contra cortocircuitos |
||||||||||||||||||||||||||||||||||||||
Conectores |
V1.0
1 x conector de placa base de 24/20 pines (600 mm) 1 x conector EPS / ATX 12V de 8/4 pines (750 mm) 4 x conector PCIE de 8/6 pines (550 mm) 8 x conector SATA ("600 mm / 150 mm / 150 mm / 150 mm "x 2) 6 x 4 pines Conector periférico (" 600 mm / 150 mm / 150 mm "x 2) 2 x 4 pines Conector de disquete (" 150 mm "x 2) V1.1 1 x 24 / 20- Pin conector de la placa base (600 mm) * 2 x 8/4-pin EPS / ATX 12V conector ("750 mm" x 2) 4 x 8/6-pin PCIE conector (550 mm) 8 x conector SATA ("600 mm / 150 mm / 150 mm / 150 mm "x 2) Conector periférico de 6 x 4 pines (" 600 mm / 150 mm / 150 mm "x 2) Conector de disquete de 2 x 4 pines (" 150 mm "x 2) |
||||||||||||||||||||||||||||||||||||||
Sistema de refrigeración |
Ventilador silencioso individual de 120 mm
|
||||||||||||||||||||||||||||||||||||||
Factor de forma | |||||||||||||||||||||||||||||||||||||||
Nivel de ruido |
18 dBA mínimo
|
||||||||||||||||||||||||||||||||||||||
Dimensión |
150 mm (W) x 86 mm (H) x 140 mm (D)
5.91 "(W) x 3.39" (H) x 5.51 "(D) |
||||||||||||||||||||||||||||||||||||||
Peso |
1,28 kg
|
||||||||||||||||||||||||||||||||||||||
Certificación |
80 PLUS Gold
|
||||||||||||||||||||||||||||||||||||||
Otro |
Lista de soporte de GPU
Compatible con ATX12V v2.4 |
