Seasonic SSE-3201PF-48 320W

Seasonic SSE-3201PF-48 320W

Seasonic
  • Universal AC input / full range.
  • High efficiency (maximum 87%).
  • Short circuit protection.
  • Overvoltage protection.
  • On the protection of power.
  • Highly Reliable 105 ° C Japanese Aluminum Electrolytic Capacitors.
  • Ball bearing fan.
  • Power LED indicator.
  • Flexible voltage adjustment by VR.

P/N: SSE-3201PF-48 - EAN/UPC: 4711173871972

62,50 € Without VAT
75,63 € With VAT
Only 1 unit left in secondary storage
Approximate delivery between 02 febrero and 02 febrero
2 years
of guarantee
Envío
shipping
100%
Secure pay

The Seasonic SSE-3201PF-48 power supply has a Universal AC input, which, added to its high efficiency, makes this power supply very versatile.

This PF series has an energy efficiency up to 87%.

It is equipped with a 60mm ball bearing fan for quiet and efficient cooling.

There is an LED indicator to show power and important protection features ensure the safety of the unit and the entire system.

The working temperature is classified between -30 ° C and 70 ° C.

These units are often used for displays, automatic door openers, and other industrial applications.

Highlights...

* Universal AC input / full range
* High efficiency (maximum 87%).
* Short circuit protection.
* Highly reliable 105 ° C Japanese aluminum electrolytic capacitors.
* Flexible voltage adjustment by VR.

Datos Generales
Potencia 320W
Eficiencia ≥ 87 %* (* ≥ 80 % for 5 V)
Entrada AC Universal Si
Conector de salida 11-Pin
Dimensiones 215 mm (fo) x 115 mm (an) x 50 mm (al)
Fanless No
Ventilador 1x 60mm Ball Bearing
S2FC Si
Protecciones SCP, OVP, OPP
Certificaciones de seguridad CB, cUL, TUV
Certificaciones EMI/EMC CE, FCC
MTBF
Active Power Factor Correction
Datos de Entrada/Salida de Corriente
Voltaje de Salida DC 12V
Carga máxima DC 6.7A
Salida total DC 320W
Votaje de Entrada AC AC 90 V ~ 264 V (47 ~ 63 Hz)
Correinte de entrada AC a 15V/230V 6A / 3A
Voltage Adjusted Rating 43.2 V ~ 52.8 V
Temperatura de funcionamiento -30º ~ 70ºC

The Seasonic SSE-3201PF-48 power supply has a Universal AC input, which, added to its high efficiency, makes this power supply very versatile.

This PF series has an energy efficiency up to 87%.

It is equipped with a 60mm ball bearing fan for quiet and efficient cooling.

There is an LED indicator to show power and important protection features ensure the safety of the unit and the entire system.

The working temperature is classified between -30 ° C and 70 ° C.

These units are often used for displays, automatic door openers, and other industrial applications.

Highlights...

* Universal AC input / full range
* High efficiency (maximum 87%).
* Short circuit protection.
* Highly reliable 105 ° C Japanese aluminum electrolytic capacitors.
* Flexible voltage adjustment by VR.

Datos Generales
Potencia 320W
Eficiencia ≥ 87 %* (* ≥ 80 % for 5 V)
Entrada AC Universal Si
Conector de salida 11-Pin
Dimensiones 215 mm (fo) x 115 mm (an) x 50 mm (al)
Fanless No
Ventilador 1x 60mm Ball Bearing
S2FC Si
Protecciones SCP, OVP, OPP
Certificaciones de seguridad CB, cUL, TUV
Certificaciones EMI/EMC CE, FCC
MTBF
Active Power Factor Correction
Datos de Entrada/Salida de Corriente
Voltaje de Salida DC 12V
Carga máxima DC 6.7A
Salida total DC 320W
Votaje de Entrada AC AC 90 V ~ 264 V (47 ~ 63 Hz)
Correinte de entrada AC a 15V/230V 6A / 3A
Voltage Adjusted Rating 43.2 V ~ 52.8 V
Temperatura de funcionamiento -30º ~ 70ºC
