Mobotix MX-VD1A-2-IR. VD-2 VandalDome.
Mobotix MX-VD1A-2-IR. VD-2 VandalDome.
- Weatherproof network cameras with H.264, H.265, ONVIF S / G / T and WDR (H.265 / ONVIF T only for 4 MP models).
- Two 4MP models, with standard or remote lenses (VD-4-IR and VD-4-IR-D).
- A FullHD / 2MP model with standard lens (VD-2-IR).
- Manual orientation of the lens holder, Vario lens with remote zoom.
- Automatic switching function between day and night with IR blocking filter.
- Integrated infrared lighting (LED, up to 30 m).
- Recording on NAS or internal SD card (not included).
- IP66, IK10, ambient temperature range: -30 to +65 ° C.
of guarantee
shipping
Secure pay
The camera allows up to simultaneous video streams of standard H.264, H.265 or M-JPEG codecs. With a maximum resolution of 4 megapixels, up to 30 images per second are generated even with the WDR (wide dynamic range) mode enabled. It will record important image details even in low visibility conditions.
This modern and very discreet dome camera due to its small size can be installed in very diverse places, such as ceilings, walls, corners or masts. You can monitor the exhibitions of a museum, the parking lot behind a company, the offices of a bank or the interior and exterior spaces of a prison.
The camera will automatically switch to day or night mode, depending on the amount of ambient light. During the day, the mechanically and electronically controlled IR blocking filter is responsible for capturing realistic color images by filtering the IR component of daylight. During the night, it changes to a black and white image, and the IR block is removed to obtain useful images even with a light of only 0.01 lux.
The integrated IR LED spotlights of the most current infrared technology guarantee a strong IR emission with minimal electricity consumption. With a uniform distribution, the camera will be able to capture important details at a distance of up to 30 m even in absolute darkness.
MOBOTIX MOVE cameras have an electronically adjustable Vario lens (remotely via camera firmware) with autofocus when the focal length is changed. You can easily adjust the view and angle of view using the focal length. The MOBOTIX MOVE VandalDome camera can be adjusted or changed at any time at a horizontal viewing angle between 35 ° (telephoto) and 103 ° (wide angle).
Highlights ...
* Weatherproof network cameras with H.264, H.265, ONVIF S / G / T and WDR (H.265 / ONVIF T only for 4 MP models).
* Two 4MP models, with standard or remote lenses (VD-4-IR and VD-4-IR-D).
* A FullHD / 2MP model with standard lens (VD-2-IR).
* Manual orientation of the lens holder, Vario lens with remote zoom.
* Automatic switching function between day and night with IR blocking filter.
* Integrated infrared lighting (LED, up to 30 m).
* Recording on NAS or internal SD card (not included).
* IP66, IK10, ambient temperature range: -30 to +65 ° C.
Product Designation | MOBOTIX MOVE VandalismDomeCamera |
Camera Type | Dome Camera |
Manual Lens Alignment | Yes |
Microphone | No |
Speaker | No |
Application Area | Indoor / Outdoor |
MxBus | No |
Color Housing | White |
Technical Data | |
Ambient Temperature | 30 ~ 60 °C |
IP Class | IP66 |
IK Class | IK10 |
Certifications | EMC: CE / FCC Safety: LVD Environment: IP66 |
MTBF | 40.000 h |
PIR | No |
Audio | Line in/out |
DVR | Support for Recording to NAS |
Protocols | ARP, PPPoE, IPv4/v6, ICMP, IGMP, QoS, TCP, UDP, DHCP, UPnP, SNMP, SMTP, RTP, RTSP, HTTP, HTTPS, FTP |
Ethernet | 10/100 Mbps Ethernet |
Overvoltage Protection | optional via Mx-Overvoltage-Protection-Box |
Mounting Options | Wall, Ceiling, Pole |
Lens Type | Vari-Focal |
Image Angle horizontal | 91,6° (Wide), 34,3° (Tele) |
Focal Length | 2.8 to 12 mm |
Aperture | f/1.4 |
Max. Frame Rate | H.264: HDR 2MP@30fps MJPEG: 1080p@30fps |
Max. Image Size | 1920 x 1080 (2MP) |
Lens | Manually adjustable vario lens |
Image Format | 16:9 |
Sensitivity |
|
Video Codec | H.264 MJPEG |
ONVIF | Profile S/G Support |
Image Sensor | 2MP, 1/3“ Progressive CMOS |
Power Consumption |
Typ: 6.6 W |
Power Supply |
|
Interfaces | RJ45, 10/100M bps Ethernet |
Dimensions | 117.4 x 133.8 mm |
Weight | 760 gr |
