MiniBarebone NUC Industrial JBC152F53316-19B

MiniBarebone NUC Industrial JBC152F53316-19B

Jetway
Intel® Bay Trail J1900 Quad Core Processor
4GB on board DDR3L 1333 MHz
16 * 100M POE LAN , 4 * Intel Gigabit LAN
Form Factor : 430 x 252 x 44 mm
AC 90~240V_400W OP Power

P/N: JBC152F53316-19B

700,00 € Without VAT
847,00 € With VAT
2 years
of guarantee
sending
shipping
100%
Secure pay
MiniBarebone NUC Industrial JBC152F53316-19B

Product Dimension

430 (W) * 252 (D) * 44 (H) mm

Product Model

JBC152F53308-1900-B
– JBC152F53316-1900-B

MB Model

JNF533-1900 / 3.5” SBC

BIOS

AMI 16MB SMT Flash ROM

CPU

INTEL® Bay Trail Processor J1900 (2.0 GHz) Quad Core

Memory

4GB on board DDR3L 1333 MHz

Storage

2.5” SATA HDD * 1

Front I/O Port

– Power Button with LED * 1
– 1000M RJ-45 * 8 & 16 (POE )

Rear I/O Port

– USB2.0 * 1 , USB3.0 * 1
– Giga LAN Port * 4
– COM * 1 (1 x RS232/422/485, 1 x RS232)
– VGA * 1
– AC-IN & AC ON-OFF

100M POE Port

– 10/100M Base-TX RJ45 Ports * 8 &16
– Conforms to IEEE802.3af, IEEE802.3at
– IEEE 802.3x full-duplex flow control , per port up to 23W
– For Switch : Marvell 88E6176
– For PoE : MAX5980

Power Source

– 400W AC-DC OP Power inside / DC12V-3A & 52V-7A
– AC 90~240V input

Accessory

– AC Cable * 1
– User Manual * 1
– Screw Package * 1

Packing

Net Weight : 4.2KG
– Gross Weight : 5KG
– Color Box Dimension : 560 (W) x 400 (D) x 380 (H) mm

Temperature

Operating within 0~60 centigrade
– Storage within -10-70 centigrade

Certification

 EMC : CE , FCC
– Safety : RoHS , Erp

Applications

– Industrial Control System
– Networking Server System
– Security Industry
