Icy Dock MB971SP-B para 2x 2.5" / 1x 3.5" SATA
- supports 2 disks: a 2.5 "and a 3.5" SATA, in a 5.25 "bay.
- Support 2.5 "HDD / SSD discs of 9.5mm thickness max. When 3.5" slot is used.
- Quick installation, without tools.
- Dust cover protects the device when no disc is inserted.
- Anti-vibration kit for 3.5 "bay.
- "Eagle-Hook" mechanism for additional protection of your data.
- Individual LEDs for each disc.
- Power buttons in order to preserve the duration of the disc
- Long ejection buttons to remove the discs in all simplicity.
- SATA III 6Gb / s compatible.
of guarantee
Insured
Secure pay
Devices that allow you to quickly change disks, in both standard SATA formats, are rare. DuoSwap revolutionizes the market because it occupies a 5.25 "bay, in which it can accommodate both a 2.5" and a 3.5 "SSD / HDD, with Hot-Swap functionality. The MB971SP-B is the rack more flexible for a space of 5.25 ", allowing different combinations either one 2.5", or one 3.5 ", or both at the same time for maximum storage. The insertion of two disks opens the doors of disk cloning, or the creation of a backup, from one format to another at SATA speed. This therefore makes the MB971SP-B the ideal tool for switching from a 3.5 "system to a 2.5" SSD. You can also take advantage of old, unused hard drives without too much pain thanks to the ease of insertion. A save of time, and money since you need a tool, and it works with virtually any hard drive that could be in the house.
The MB971SP-B is ideal in terms of quick installation since they can for example have their operating system on a 2.5 ”SSD, and their main storage unit in the 3.5” bay. In addition, to avoid the problems related to the degradation of the material, we provided a dust mask in the case or only a 2.5 ”disk would be used. Makes maintenance more accessible, thanks to the individual eject and power buttons, as well as the monitoring of the discs due to the LEDs associated with each of the discs. The power buttons allow you to turn off individual discs when not in use, in order to save power and extend the life of the discs. The device uses 2 SATA connectors for data exchange, and a single power connector to limit compatibility issues. We also integrated an “Eagle-Hook” mechanism for additional disc security. This activates automatically when the 3.5 ”disk is fully inserted, closing it in place.
The MB971SP-B functions in the same way as the external host stations, but has numerous advantageous functionalities in relation to the others, such as LEDs, power / eject button. It allows the user to connect in parallel the 2 formats of hard drives, 2.5 "and 3.5", HDD and also SSD.
Highlights..
* supports 2 drives: a 2.5 "and a 3.5" SATA, in a 5.25 "bay.
* Support 2.5 "HDD / SSD discs of 9.5mm thickness max. When 3.5" slot is used.
* Quick installation, without tools.
* VCompatible SATA III 6Gb / s ..
* Dust cover protects the device when no disc is inserted.
Color | Negro |
Interfaz | 7 pin SATA x 2 |
Disco | 2.5" SATA HDD o SSD x 1 (9.5mm - 12.5mm altura) 3.5" SATA HDD o SSD x 1 |
Bahía | 1 x 3,25 |
Tasa de transferencia | 2.5" SATA I / II / III HDD & SSD (9.5mm)) |
Bahía | 1 x bahía de 3,5” |
Tasa de transferencia | Hasta 6 Gb/sec. (según la velocidad del disco) |
Inserción y extracción via | 15 pin de conexión directa al disco duro |
Estructura | Metal |
Alimentación | 15pin SATA Power |
Indicador LED | Alimentación y actividad del disco |
Color de visualización LED | Verde : alimentación ; Ámbar : Actividad del disco |
Dimensión (L x W x H) | 147.8 x 42 x 178.2mm |
Peso neto del producto | 623g |
Humedad | 5%~65% HR |
Temperatura de funcionamiento | 0°C a 60°C (32°F a 140°F) |
Temperatura de almacenamiento | -35°C a 70°C (-31°F a 158°F) |
Devices that allow you to quickly change disks, in both standard SATA formats, are rare. DuoSwap revolutionizes the market because it occupies a 5.25 "bay, in which it can accommodate both a 2.5" and a 3.5 "SSD / HDD, with Hot-Swap functionality. The MB971SP-B is the rack more flexible for a space of 5.25 ", allowing different combinations either one 2.5", or one 3.5 ", or both at the same time for maximum storage. The insertion of two disks opens the doors of disk cloning, or the creation of a backup, from one format to another at SATA speed. This therefore makes the MB971SP-B the ideal tool for switching from a 3.5 "system to a 2.5" SSD. You can also take advantage of old, unused hard drives without too much pain thanks to the ease of insertion. A save of time, and money since you need a tool, and it works with virtually any hard drive that could be in the house.
The MB971SP-B is ideal in terms of quick installation since they can for example have their operating system on a 2.5 ”SSD, and their main storage unit in the 3.5” bay. In addition, to avoid the problems related to the degradation of the material, we provided a dust mask in the case or only a 2.5 ”disk would be used. Makes maintenance more accessible, thanks to the individual eject and power buttons, as well as the monitoring of the discs due to the LEDs associated with each of the discs. The power buttons allow you to turn off individual discs when not in use, in order to save power and extend the life of the discs. The device uses 2 SATA connectors for data exchange, and a single power connector to limit compatibility issues. We also integrated an “Eagle-Hook” mechanism for additional disc security. This activates automatically when the 3.5 ”disk is fully inserted, closing it in place.
The MB971SP-B functions in the same way as the external host stations, but has numerous advantageous functionalities in relation to the others, such as LEDs, power / eject button. It allows the user to connect in parallel the 2 formats of hard drives, 2.5 "and 3.5", HDD and also SSD.
Highlights..
* supports 2 drives: a 2.5 "and a 3.5" SATA, in a 5.25 "bay.
* Support 2.5 "HDD / SSD discs of 9.5mm thickness max. When 3.5" slot is used.
* Quick installation, without tools.
* VCompatible SATA III 6Gb / s ..
* Dust cover protects the device when no disc is inserted.
Color | Negro |
Interfaz | 7 pin SATA x 2 |
Disco | 2.5" SATA HDD o SSD x 1 (9.5mm - 12.5mm altura) 3.5" SATA HDD o SSD x 1 |
Bahía | 1 x 3,25 |
Tasa de transferencia | 2.5" SATA I / II / III HDD & SSD (9.5mm)) |
Bahía | 1 x bahía de 3,5” |
Tasa de transferencia | Hasta 6 Gb/sec. (según la velocidad del disco) |
Inserción y extracción via | 15 pin de conexión directa al disco duro |
Estructura | Metal |
Alimentación | 15pin SATA Power |
Indicador LED | Alimentación y actividad del disco |
Color de visualización LED | Verde : alimentación ; Ámbar : Actividad del disco |
Dimensión (L x W x H) | 147.8 x 42 x 178.2mm |
Peso neto del producto | 623g |
Humedad | 5%~65% HR |
Temperatura de funcionamiento | 0°C a 60°C (32°F a 140°F) |
Temperatura de almacenamiento | -35°C a 70°C (-31°F a 158°F) |
