HPE OfficeConnect 1820-8G. Switch 8 Puertos.
- Customized operation using intuitive Web interface.
- Flexible deployment options including wall, under table, and desktop mounting.
- 8-, 24- and 48-port non-PoE+ models are fanless for quiet operation.
of guarantee
Insured
Secure pay
The HPE 1820 switch series offers more options and flexibility for small companies that require ease of use and reduce total cost of ownership (TCO), while offering better network performance. They are Layer 2 Gigabit Ethernet switches with intelligent management and fixed configuration in an easy-to-manage solution that has the latest energy-saving capabilities. These switches are plug-and-play ready to use, in which the network operation can be adjusted through the functions available from a graphical user interface based on a simple web browser, when you need it.
The HPE 1820 series of switches have an intuitive web management interface with an improved navigation panel to facilitate the management of devices by users without technical knowledge. The HPE 1820 switch series is ideal for companies that require simplicity.
The series offers you flexibility and the possibility to choose with a complete range. It obtains six rack-mount models including three models without power over Ethernet (PoE). Some models include SFP ports for fiber optic connectivity.
Customizable features include VLAN, expansion tree, trunk link aggregation and IGMP search. All models include the Rapid Expansion Tree Protocol (RSTP) and DSCP QoS policies.
These switches support flexible installation options, including wall mounting, under tables or on desks.
Some models do not include a fan, which makes them silent for office implementations.
The HPE 1820 switch series features the latest energy-saving capabilities, including Energy Efficiency Ethernet (IEEE), inactive port shutdown and PoE port programmer.
The 8-port Gigabit Ethernet model can be powered by an upstream through a PoE switch for environments where line power is not available.
Highlights...
* Intuitive web management interface with an improved navigation panel.
* Non-PoE and PoE + models for deployment flexibility.
* Fanless design available on all four models for quiet operation.
* Customizable functions for greater network performance.
| Ports | 8x Puertos RJ-45 10/100/1000 con detección automática Admite un máximo de 8 puertos 10/100/1000 con detección automática |
| Memory and processor | ARM Cortex-A9 a 400 MHz 128 MB de SDRAM Tamaño de búfer para paquetes: 1,5 MB 16 MB de flash |
| Latency | Latencia de 100 Mb: < 7 µs Latencia de 1000 Mb: < 2,4 µs |
| Speed | hasta 11,9 Mpps |
| Routing capacity | Máximo de 104 Gbps, según la configuración |
| Switching capacity | 16 Gbps |
| Management functions | Navegador Web |
| Input voltage | 100 - 240 VCA, clasificado (según la fuente de alimentación elegida) |
| Energy consumption | 12,2 W (máximo) |
| Minimum dimensions | 25,4 x 15,95 x 4,39 cm |
| Weight | 0.82 Kg |
