Español HighPoint RocketRaid 3740A SATA/SAS
HighPoint RocketRaid 3740A SATA/SAS
- HighPoint extends the 12 Gb / s SAS RAID controllers with the 8 ports of this device.
- High-performance, professional-grade 12G PCIe 3.0 RAID storage.
- Ready for any workstation and server platform.
- Multi-HBA solution.
The price that appears is indicative
of guarantee
Insured
Secure pay
The RocketRAID 3700 host bus adapters are the world's most competitive 12G SAS / SATA RAID controllers and deliver next-generation PCI Express 3.0 transfer performance with professional-class RAID Storage management and reliability capabilities.
RocketRAID 3700 Series Host Bus Adapters leverage HighPoint's two decades of RAID and storage technology to deliver professional-grade RAID storage at a fraction of the cost of conventional host RAID solutions. Each adapter is powered by our industry-proven RAID technology, PCI Express 3.0 express transfer bandwidth, and up to sixteen dedicated 12 Gb / s SAS channels, supporting RAID 0, 1, 5, 6, 10, 50 and JBOD configurations of SAS or SATA hard drives of any disk format, including 512, 512e and 4Kn.
HighPoint offers a range of customized solution services for SMB clients. We can tailor RocketRAID 3700 host bus adapters to meet the requirements of customer-defined storage applications on Linux, Windows, Mac, and FreeBSD platforms, and we are ready to assist Solution Providers with a unique product brand. A complete API library is available for integration projects and we offer a variety of Enclosure Management services including SGPIO, SES-2 and I2C.
Highlights ...
* Supported storage disk interfaces: SAS, Host interface: PCI Express x8.
* Other supported operating systems: Windows, Linux, FreeBSD and Mac OS X Operating System.
* Certificates: FCC, CE, ROHS & REACH.
| Puertos e Interfaces | ||||
| Interno | Si | |||
| Interfaz del host | PCIe x8 | |||
| Interfaz de salida | SAS | |||
| Niveles RAID | 0, 1, 5, 6, 10, 50 & JBOD | |||
| Ancho de banda | 12 Gbit/s | |||
| Diseño | ||||
| Tiempo medio entre fallos | 920,585 Horas | |||
| Certificaciones | CE, FCC, ROHS, REACH | |||
| Condiciones ambientales | ||||
| Temperatura operativa | 5 - 55 ºC | |||
| Peso y dimensiones | ||||
| Ancho | ||||
| Fondo | ||||
