Español Gigabyte Z390 Gaming X. Socket 1151.
Gigabyte Z390 Gaming X. Socket 1151.
- Processor socket: LGA 1151 (Socket H4).
- Compatible processor: Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium.
- Supported memory types: DDR4-SDRAM.
- Supported memory clock speeds: 2133,2400,2666 MHz.
- Types of hard drives, SSD.
- Support for parallel processing: 2-Way CrossFireX, Quad-GPU CrossFireX.
- Ethernet interface type: Gigabit Ethernet.
of guarantee
shipping
Secure pay
GIGABYTE GAMING series motherboards use a lower 10 * + 2 phase PWM + RDS MOSFET design (on) to support the latest 8-core Intel® Core ™ CPUs by delivering incredible precision in delivering power to the motherboards with higher power consumption and energy sensitive components, as well as offering improved system performance and maximum hardware scalability.
Multiple cutouts on the heat sinks improve thermal performance by increasing the heat dissipation surface and maintaining a sleek aesthetic.
The improved thickness of the thermal pad to 1.5mm provides superior heat dissipation from MOSFETs.
Multi-graphic configurations offer superior performance for gaming enthusiasts who demand maximum fps without compromising resolution.
Intel® GbE LAN features cFosSpeed, a network traffic management application that helps improve network latency and keep ping times low to provide better responsiveness in crowded LAN environments.
Highlights ...
* Processor socket: LGA 1151 (Socket H4).
* Compatible processor: Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium.
* Supported memory types: DDR4-SDRAM.
* Supported memory clock speeds: 2133,2400,2666 MHz.
* Types of hard drives, SSD.
* Support for parallel processing: 2-Way CrossFireX, Quad-GPU CrossFireX.
* Ethernet interface type: Gigabit Ethernet.
| Procesador | Support for 9th and 8th Generation Intel® Core™ i9 processors/ Intel® Core™ i7 processors/ Intel® Core™ i5 processors/ Intel® Core™ i3 processors/ Intel® Pentium® processors/ Intel® Celeron® processors in the LGA1151 package Caché L3 varía según la CPU |
| Chipset | Intel Z390 Express |
| Memoria | 4 x DDR4 DIMM sockets supporting up to 128GB (32GB single DIMM capacity) of system memory** ** Please note that the support for system total memory size depends on the CPU installed. Arquitectura de memoria Dual Channel Support for DDR4 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 MHz memory modules Soporte para módulos de memoria ECC Un-buffered UDIMM 1Rx8/2Rx8 (operando en modo no-ECC) Soporte para módulos de memoria non-ECC Un-buffered DIMM 1Rx8/2Rx8 Soporte para módulos de memoria Extreme Memory Profile (XMP) |
| Gráficos | 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz * Support for HDMI 1.4 version and HDCP 2.2. |
| Audio | Codec Realtek® ALC892 Audio de alta definición 2/4/5.1/7.1-channel Soporte para salida S / PDIF |
| LAN | Chip Intel® GbE LAN (10/100/1000 Mbit) |
| Slots de expansión | 1 x PCI Express x16, a x16 (PCIEx16) * Para un rendimiento óptimo, aunque sea con una única tarjeta gráfica PCI Express instalada, asegúrese de conectarla en la ranura PCIEx16. 1 x PCI Express x16, a x4 (PCIEX4) 4 x PCI Express x1 slots (Todos los slots PCI Express conforman el estandar PCI Express 3.0) |
| Almacenamiento | 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe x4/x2 SSD support) (M2A) 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD support) (M2M) 6 x conector SATA 6Gb/s Soporta RAID 0, RAID 1, RAID 5, y RAID 10 * Consulte "1-7 Conectores internos" para obtener los avisos de instalación de los conectores M.2 y SATA. |
| Multi-GPU | Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies |
| Conectores internos | 1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 1 x conector de alimentación ATX 12V 8-pin 1 x conector del ventilador de la CPU 3 x conector del ventilador del sistema 1 x RGB LED strip header 6 x conector SATA 6Gb/s 2 x conectores M.2 Socket 3 1 x front panel header 1 x front panel audio header 1 x conector S/PDIF Out 1 x cabezal USB 3.1 Gen 1 1 x conector USB 2.0/1.1 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) La función TPM es opcional según las diferentes políticas locales 1 x Tarjeta expansión Thunderbolt™ 1 x conector del puerto de serie 1 x Clear CMOS jumper |
| Panel trasero E/S | 1 x puerto teclado / ratón PS / 2 1 x HDMI 1 x puerto USB 3.1 Gen 2 Type-A (rojo) 5 x puertos USB 3.1 Gen 1 2 x puerto USB 2.0/1.1 1 x Puerto RJ-45 6 x audio jacks |
| BIOS | 2 x flash de 128 Mbit Licencia para uso de UEFI BIOS de AMI Soporta DualBIOS™ PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Formato | Factor de forma ATX: 30,5cm x 22,5cm |
| Sistema Operativo | Support for Windows 10 64-bit |
