Español Chenbro JBOB RM43260D3-RB00B Rack 4U con 60 bahías HD con fuente 1100W redundante y 3R. No MB
Chenbro JBOB RM43260D3-RB00B Rack 4U con 60 bahías HD con fuente 1100W redundante y 3R. No MB
- 4U Rack Box.
- Supports up to 60 SAS / SATA 3.5 drives, with a maximum speed of 12Gb / s.
- Includes 1100W 80+ Gold redundant power supply.
- Redundant, hot-swap fan modules.
- Easy maintenance and installation.
of guarantee
shipping
Secure pay
The Chenbro RM43260 is an impressive 4U rack enclosure, capable of storing up to 60 3.5 "SATA / SAS drives. Specifically designed to ensure optimal performance in server data storage applications, with multiple redundancy for data protection.
High flexibility. The RM43260 has a very flexible expandability, designed to meet all the requirements for different types of applications. The four SFF-8644 ports can be configured for Host or Cascade connection. Note that 12Gb / s SAS3 drives offer ample capacity for today's fastest drives, fully utilizing controller performance and reducing external cabling.
This rack box incorporates a redundant 1100W power supply, with 80+ Gold certification and intelligent control of the fans. This ensures a form of use and significant energy savings.
The fan modules are also redundant and allow hot swapping. These modules have four front fans and four in the middle. These modules have an isolation system to protect the system from vibrations and reduce noise at a general level. Fan controllers employ an algorithm to ensure fan speed changes are as smooth as possible.
As if that were not enough, the RM43260 box is also designed to make installation and maintenance the easiest thing to do. The top covers can be removed without the use of tools, and it has a 36 "rail with a travel of up to 760mm, with a maximum load of 120Kg.
Highlight ...
* Rack 4U box.
* 60 3.5 "Hot-swap bays.
* Redundant 1100W 80+ Gold power supply.
* Redundant and hot swap fan modules.
* Easy maintenance and installation.
| Datos
Generales |
||||
| Factor de forma | 4U | |||
| Factor de forma M / B | - |
|||
| Dimensiones | 888 x 438.5 x 176 mm | |||
| Bahias de unidad | 60x Hot-swap 3.5" |
|||
| Factor de forma fuente de alimentación | 1 + 1 Redundante, 1100W 80Plus Oro (auto encendido) | |||
| Indicadores | 1x Estado alimentación 60x Actividad del HDD 8x Aviso de fallo de ventilador 1x Leds controladores de estatus de SAS interno, sobrecalentamiento y fallo de fuente de alimentación |
|||
| Panel Frontal | 1x Boton encendido / apagado 1x Apagado de alarma |
|||
| Ventiladores | Frontal: 4 x 80mm (T = 38mm), PWM, Hot-swap Medio: 4 x 80mm (T = 38mm), PWM, Hot-swap |
|||
| Ranura de expansión | - |
|||
| HDD Backplane | 2x 30 puertos 12 Gb/s SAS
Expander |
|||
| Peso | 36.2 ~ 62 Kg | |||
| Fuente de alimentación | 1100W 80Plus Oro redundante. | |||
