Barco ClickShare CSE-800

Barco ClickShare CSE-800

Barco
  • Resolution: 4K DCI (4096x2160) at 60 Hz.
  • Authentication protocol: WWPA2-PSK in standalone mode.
  • Noise level: Max. 25 dBA at 030 ° C.
  • Frequency band: 2.4 GHZ and 5 GHz.
  • Anti-theft system: Kensington lock.
  • Application: Business Events / Presentation Server.
  • Number of users: Up to 8 users on the screen simultaneously.

P/N: R9861580EU - EAN/UPC: 5400503000128

Alisa
4.213,58 € Without VAT
5.098,43 € With VAT
2 years
of guarantee
sending
shipping
100%
Secure pay

The CSE-800 includes two HDMI outputs and inputs. There is a direct connection to existing equipment and integration is easy with conference systems. In addition, the two 4K DCI displays can be controlled from a single Base Unit. Furthermore, the 2 network connections allow simultaneous and independent connection with various networks, eg. eg corporate networks and guest attendee networks, and offers an extra level of security and convenience for users. The CSE-800 allows eight people to share your content simultaneously. Plus, it ensures direct connectivity to the central display and encourages collaboration.

The moderation feature was specifically designed for use in larger rooms, where multiple attendees want to share content at once. To avoid rapid screen switching, making it difficult to follow content, a moderator can manually select what content will appear on the screen and when, to ensure the best experience for all attendees. The moderation feature can be disabled at any time, to return the system to ClickShare normal operating mode, to share content with the click of a button. For the user's convenience, the security features of the CSE-800 can be set to one of three predefined levels, based on company policy and needs.

ClickShare introduces the Touch Back function and brainstorming in boardrooms. Run any application from the laptop and control it from the screen. With a few gestures on the screen, open presentations, share emails and play videos. Reach out to the audience and content, rather than worrying about the presentation tool.

The CSE-800 is also one of the basic components of Barco Ideation Wall for collaborative and interactive meetings. Just by combining a Barco UniSee LCD video wall, a touch frame specifically designed for Barco UniSee and a ClickShare CSE-800 that supports annotation, whiteboard and Touch Back functionality from the first moment, you will create a unique and unified experience in your living room. meetings that will allow you to enjoy both the interactivity features offered by our ClickShare wireless collaboration solution and Barco UniSee's seamless viewing experience, never before seen on LCD video walls.

The CSE-800 is an ISO 27001 certified product.

Highlights...

* Up to 8 users simultaneously.
* 1 user sharing content on the screen.
* Share from laptop, tablet or smartphone.
* Enhanced security features.
* 4K DCI resolution.

Especificaciones Generales
Sistema Operativo Windows 7/8/8.1/10 32 y 64 bits
macOS 10.14/10.15 (Catalina)
Android 9 y 10 (ClickShare app)
iOS 11, 12 y 13 (ClickShare app)
Salidas de video 2x HDMI
Entradas de video 2x HDMI
Resolución de salida 4K DCI (4096x2160) a 60 Hz
Resolución de entrada 4K DCI (4096x2160) a 60 Hz
Audio Mediante HDMI, analógico con toma de audio de 3.5mm, S/PDIF
Compatible con AirPlay Duplicación de pantalla en iOS (AirPlay) desde iOS 9.0 hasta iOS 12 / Mac OS 10.14
Compatibilidad con Google Cast Android 8.1 Oreo
Frecuencia de cuadro Uso de entradas HDMI:
Hasta 60 fps con una entrada con una resolución de 4K
Hasta 30 fps con dos entradas con una resolución de 4K*

Con el ClickShare Button o las aplicaciones:
Hasta 30 fps con una resolución de 1080p
Nº Fuentes simultáneas 8 (4 por pantalla)
Nº Conexiones simultáneas 64
Compatible con iPad, iPhone, Android Compartir documentos, el explorador y la cámara de dispositivos Android e iOS mediante Clickshare app.
Escritorio extendido Disponible (según el sistema operativo). Podría necesitar paquete de ampliación de ClickShare.
Protocolo de autenticación WPA2­PSK en modo independiente
WPA2-PSK o IEEE 802.1X usando ClickShare Button en modo de integración de red
Protocolo de transmisión WiFi IEEE 802.11 a/b/g/n e IEEE 802.15.1
Alcance Ajustable con modulación de intensidad de la señal; máximo de 30 m (100 pies) entre
ClickShare Button y ClickShare Base Unit
Banda de frecuencia 2.4 Ghz y 5 Ghz
Conexiones 2x LAN Ethernet de 1 Gbit
2x USB 2.0; 2x USB 3.0 (detrás); 2x USB 3.0 (delante)
Salida de línea analógica en toma jack miniatura (3,5 mm), S/PDIF digital
Nivel de ruido Máx. 25 dBA a 0­30 °C
Máx. 30 dBA a 30­40 °C
Rango de temperatura Funcionamiento: 0 a +40 °C (+32 a +104 °F)
Máx: 35 °C (95 °F) a 3000 m
Almacenamiento: ­20 a -60 °C (­4 a +140 °F)
Humedad Almacenamiento: de 0 a 90 % de humedad relativa, sin condensación
Funcionamiento: de 0 a 85 % de humedad relativa, sin condensación
Sistema antirrobo Cierre Kensington
Certificaciones FCC/CE
Dimensiones de la unidad base ClickShare
Dimensiones (Al x An x P) 46,2 mm x 282,3 mm x 206,5 mm (sin antenas) / 1,8" x 11,1" x 8,1"
146,4 mm x 282,3 mm x 206,5 mm (con antenas) / 5,8"x 11,1" x 8,1"
Fuente de alimentación Conexión 110/220 V CA estándar
Consumo Funcionamiento normal:
90 W en condiciones de uso completo
52 W en condiciones de uso normal (conectar 2 salidas HDMI, conectar 1 entrada HDMI, compartir con 4 personas)
modo ECO: 30 W
Modo en espera en red: < 1 W
Modo en espera profundo: < 0,5 W
Peso 2,2 kg/4,85 lbs
