Asus WS C246M Pro. Socket 1151. Micro-ATX.
Asus WS C246M Pro. Socket 1151. Micro-ATX.
- Optimized cooling design to enhance the stability of rack configurations.
- Supports up to three independent screens via HDMI, DisplayPort and VGA.
- M.2 offers transfers of up to 32 Gbps.
- USB 3.1 ports provide transfer speeds of up to 10 Gbps.
- Two Intel Gigabit LAN with bandwidth aggregation.
- ASUS Control Center: A convenient and safe utility designed for centralized management of SMEs.
of guarantee
shipping
Secure pay
The WS C246M PRO is an ideal workstation motherboard for video streaming applications, cloud gaming and media server. It presents an optimized refrigeration design for rack configurations that increases stability and allows you to take advantage of the full potential of the components.
It is compatible with the Intel Xeon E family, a series of processors that offers premium performance optimized for non-stop work applications. On the other hand, ECC (Code Error Correction) memory modules automatically correct one-bit errors to make your workstation more reliable, prevent data from getting corrupted and the system from crashing.
Equipped with HDMI, DisplayPort and VGA ports, the WS C246M PRO offers great versatility in multi-screen applications. Install a next-generation Intel compatible processor and you can multiply your productivity by working simultaneously with up to three independent screens.
Equipped with a PCIe 3.0 x4 interface, the M.2 slot supports transfer speeds of up to 32 Gbps, up to 5.3 times faster than traditional SSDs. The WS C246M PRO is compatible with the latest 2.5-inch NVMe SSD drives.
The WS C246M PRO has two front USB 3.1 Gen. 2 connectors that support transfers of up to 10 Gbps, double that of USB 3.1 Gen. 1.
SafeSlot is a new PCI Express slot design created by ASUS that provides more retention strength and transverse resistance. Manufactured in a single step by insert molding, the SafeSlot slot incorporates metal reinforcements that make it much more resistant and are attached to the PCB by additional welding points.
Highlights...
* Optimized cooling design for rack configurations.
* Compatible with Intel Xeon E processors and ECC memory.
* Supports simultaneously up to three independent screens.
* Accelerates data access to 32 Gbps with M.2.
* USB 3.1 with transfer speeds of up to 10 Gbpss.
* SafeSlot.
* ASUS Control Center.
Processor | |
Processor family | Intel |
Compatible processor | Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium, Intel Xeon |
Socket | LGA 1151 |
Memory | |
Compatible types | DDR4-SDRAM |
Slot types | DIMM |
Nº Slots | 4 |
Speeds supported | 2133, 2400, 2666 MHz |
Module capacity | |
Max. internal memory | 64GB |
Ethernet | |
Ethernet | 1x Intel I210AT 1x Intel I219LM |
Internal I/O | |
USB 2.0 | 2 |
USB 3.0 ( 3.1 Gen 1 ) | |
USB 3.1 ( 3.1 Gen 2 ) | |
USB 3.2 ( 3.1 Gen 1 ) | 1 |
Rear panel I/O ports (Input/Output) | |
USB 2.0 | 2 |
USB 3.2 ( 3.1 Gen 1 ) | 2 |
USB 3.2 ( 3.1 Gen 2 ) | 2 |
RJ45 | 2 |
PS/2 | |
HDMI | 1 |
DVI-D | 1 |
VGA | 1 |
Expansion slots | |
PCI Express x1 (Gen 2.x) | 1 |
PCI Express x4 (Gen 3.x) | 1 |
PCI Express x16 (Gen 3.x) | 1 |
Performance | |
Format | Micro-ATX |
Chipset | Intel C246 |
GPU | |
Audio system | |
Audio output channels | 8.0 |
Dimensions | 244 x 244mm |
