Arctic P14 PWM PST 140x140x25

Arctic P14 PWM PST 140x140x25

Arctic
  • Optimized for static pressure.
  • More efficient technology.
  • Maximum softness, minimum vibration.
  • Improved lifespan.
  • It changes from 200 to 1950 rpm regulated by PWM PST.

P/N: ACFAN00125A - EAN/UPC: 4895213701563

6,50 € Without VAT
7,87 € With VAT
In stock
Delivery 24/48h working
3 years
of guarantee
Shipment
Insured
100%
Secure pay

Otros clientes que vieron este producto también se interesaron en
2,78 €
Without VAT
3,36 €
With VAT
Xigmatek ACK-I7751 S775
43,75 €
Without VAT
52,94 €
With VAT
Arctic Freezer 50 TR

During the development of the new P14 PWM PST, particular emphasis was placed on a concentrated air stream and thus high static pressure. The fan ensures extremely efficient cooling, even with increased air resistance. Therefore, the P14 PWM PST is particularly suitable for use in heat sinks and radiators.

The motor is driven by a state-of-the-art neodymium-iron-boron magnet ring, which enables the new P14 PWM PST to run much more efficiently than its predecessors. This saves energy and reduces coil temperature without compromising performance.

Even at low speeds, the running sound of the new ARCTIC motor is barely perceptible. Due to sinus magnetization, the new motor only creates about 5% of the commutation vibration of a normal unfiltered DC motor. Consequently, there is no need for rubber spacers due to the constant and smooth torque of the new motor.

A 10 ° C lower motor temperature roughly doubles the life of a fan. The new ARCTIC motor has four times longer service life thanks to its low coil temperature.

With a wide range of regulation and PWM Sharing Technology (PST), the speed of the P14 PWM PST fan can be controlled synchronously with all other fans together. This keeps noise to a minimum while ensuring maximum cooling performance when needed.

Thanks to an alloy / lubricant combination developed in Germany, friction within the bearing is reduced and greater efficiency is achieved. As a result, there is less heat development and less noise in the bearings, which means you can enjoy a longer life from your fan.

Highlights...

* Optimized for static pressure.
* More efficient technology.
* Maximum softness, minimum vibration.
* Improved lifespan.
* Changes from 200 to 1950 rpm regulated by PWM PST.


Velocidad 200-1700 rpm
Flujo de aire 72.8 CFM / 123.76 m³ / h
Presión estatica 2,40 (mm / H2O)
Nivel de ruido: 0.3 sone
Tipo de control PST
Conexión Conector de 4 pines + enchufe de 4 pines
Voltaje típico 12 V CC
Amperaje 0,12 A
Longitud del cable 400mm
Ancho x Alto x Fondo 140mm x 140mm x 27mm
Peso 194Gr

During the development of the new P14 PWM PST, particular emphasis was placed on a concentrated air stream and thus high static pressure. The fan ensures extremely efficient cooling, even with increased air resistance. Therefore, the P14 PWM PST is particularly suitable for use in heat sinks and radiators.

The motor is driven by a state-of-the-art neodymium-iron-boron magnet ring, which enables the new P14 PWM PST to run much more efficiently than its predecessors. This saves energy and reduces coil temperature without compromising performance.

Even at low speeds, the running sound of the new ARCTIC motor is barely perceptible. Due to sinus magnetization, the new motor only creates about 5% of the commutation vibration of a normal unfiltered DC motor. Consequently, there is no need for rubber spacers due to the constant and smooth torque of the new motor.

A 10 ° C lower motor temperature roughly doubles the life of a fan. The new ARCTIC motor has four times longer service life thanks to its low coil temperature.

With a wide range of regulation and PWM Sharing Technology (PST), the speed of the P14 PWM PST fan can be controlled synchronously with all other fans together. This keeps noise to a minimum while ensuring maximum cooling performance when needed.

Thanks to an alloy / lubricant combination developed in Germany, friction within the bearing is reduced and greater efficiency is achieved. As a result, there is less heat development and less noise in the bearings, which means you can enjoy a longer life from your fan.

Highlights...

* Optimized for static pressure.
* More efficient technology.
* Maximum softness, minimum vibration.
* Improved lifespan.
* Changes from 200 to 1950 rpm regulated by PWM PST.


Velocidad 200-1700 rpm
Flujo de aire 72.8 CFM / 123.76 m³ / h
Presión estatica 2,40 (mm / H2O)
Nivel de ruido: 0.3 sone
Tipo de control PST
Conexión Conector de 4 pines + enchufe de 4 pines
Voltaje típico 12 V CC
Amperaje 0,12 A
Longitud del cable 400mm
Ancho x Alto x Fondo 140mm x 140mm x 27mm
Peso 194Gr
